Sumiko Olympia MM Cartridge

Sumiko Olympia MM Cartridge

Olympia implements an upgraded cantilever assembly that reduces moving mass, translating to more nimble groove tracing, extended nuance and expanded frequency response.

Regular price £239.00 GBP
Regular price Sale price £239.00 GBP
Sale Sold Out

Description

Olympia

Olympia implements an upgraded cantilever assembly that reduces moving mass, translating to more nimble groove tracing, extended nuance and expanded frequency response.

  • Dynamic performance with greater refinement
  • Overhead mounting cartridge for installing into a headshell
  • Moving magnet cartridge with removable stylus
  • Low-resonance body and generator system
  • Tipped Elliptical diamond stylus profile

Olympia

The Olympia features a finely polished elliptical stylus for a level of acoustic refinement that defies belief. In combination with the range's integrated body and generator system that significantly reduces internal resonances, the Olympia delivers greater dynamic punch from a broad frequency response. The improved stylus also sits on a bespoke cantilever, mounted to a smaller magnet for more precise movements resulting in greater channel separation and a slightly lower but still powerful 4mV output.

Latest Generation Oysters

Designed for discerning, value-minded audiophiles, Sumiko's latest generation premium moving magnet Oysters build upon, enhance and refine the sonic character that listeners worldwide have enjoyed for decades. The cartridge body design addresses the problem of resonance by dispersing and dissipating it away from the generator system resulting in a sound quality, reminiscent of moving coil designs.

Made in Japan

From Oyster to Reference, each Sumiko phono cartridge is crafted by hand in Yokohama, Japan — near the waters where their namesake Oysters dwell. They’ve selected by ear the finest materials that combine to deliver performance that has enlightened generations of listeners. Each design is thoroughly auditioned until perfected. Production is then executed by world-class cartridge makers with a collective eye for precision and quality.

Specifications

  • Output Voltage
    4 mV
  • Channel Balance (@ 1000Hz)
    1.5 dB
  • Channel Separation (@ 1000Hz)
    30 dB
  • Channel Separation (@ 15000Hz)
    15 dB
  • Frequency Range (@ -3dB)
    6000 Hz
  • Frequency Response
    12 - 30,000 dB
  • Tracking Ability (@ 315Hz at Recommended Tracking Force)
    60 μm
  • Compliance, Dynamic, Lateral
    12 μm
  • Stylus Type
    0.3 x 0.7mil Elliptical
  • Tracking Force Range
    1.8 - 2.2 g
  • Recommended Tracking Force
    2.0 g
  • Tracking Angle
    25 °
  • Internal Impedance
    1130 Ω
  • Internal Inductance
    450 mH
  • Magnet Type
    Alnico
  • Cantilever Material
    Aluminium Tube
  • Coil Wire Material
    Pure Copper
  • Recommended Load Impedance
    47000 Ω
  • Recommended Load Capacitance
    100 - 200 pF
  • Cartridge Weight
    6.5 g

1 Year Warranty

The warranty period starts from the date of purchase and covers you from manufacturing defects & unexpected faults through normal use. It does NOT cover you from accidental damage, damage caused by usage outside of product specifications or expected product wear and tear.
